SYSTEMS AND MAGIC

BlackWire plus+

The BlackWire is a mains cable with semi-balanced geometry, shielded, twisted, with an area of 2.5mmq for each conductor. Despite the 11mm external diameter, it keeps excellent flexibility in all conditions.

BlackWire use is advised in conjunction with filters and power distributors of the BlackNoise line, particularly on the output of the devices themselves.

Shielding, for example, avoids the

cable to act as an antenna, either receiving or radiating electromagnetic energy and allows the cleanliness performed by the BlackNoise filters to reach unimpaired the electronic inlets.

About this topic see also questions 8 and 9 in the FAQ.

But that’s not the only reason: the Schuko plug guarantees the best possible mechanical and electrical coupling (See also question 7 in the FAQ), and the

e-mail: info@systemsandmagic.com

Via Raffaele Piria 17

00156 Roma (RM) - Italy

Voice +39-06-40500329 / +39-06-99259892 / +39-338-8928518

Fax +39-06-62276249 - Skype: systemsandmagic_lab

M A D E I N I T A L Y

S Y S T E M S A N D M A G I C

The BlackWire plus+ diverts from the standard BlackWire for it adopts an excellent Wattgate as the current IEC plug, the same used for the much more costly GoldWire.

All the options available for the standard BlackWire (lengths and different terminations), are still offered for the BlackWire plus+ without price variations.

¹ Of the three available plugs, mains side, only the Schuko can (and is!) soldered to the cable.

The BlackWire is normally available in 1.5 meters standard length, IEC and Schuko terminated as shown in the photos.

Longer cables are available on request, with an additional €25 for each meter or fraction. For cables shorter than the standard there is a fixed €25 euro addition.

In place of the Schuko plug is available either the Italian style 16A plug, or the US plug at the additional price of €20 and €40 respectively.

Finally, in place of the straight IEC inlet is available the right angle one at the additional price of 20€.

internal connections, either plug and inlet side, are soldered¹ assuring the maximum possible contact area and at the same time the performance consistency over time.

Cabling, finally, follows the IEC standard for neutral and phase, this one also marked on the mains plug.

At a particularly affordable price, the BlackWire represents an excellent alternative to more expensive cables without any limitation in terms of power constraint or interference protection.

To gain even more performance, see BlackWire plus+, GoldWire.

Standard BlackWire IEC plug

Read the

BlackWire/GoldWire

brochure in PDF format

English German

√

Adaptors able to interface the BlackWire (or any other of our mains cables, see joker, GoldWire, GoldWire plus+, Pearl) with IEC C7 or C5 sockets are available at €20,00.
